Bond Gold (ECH17) Vinyl Wrap

Description

Fashionable and luxurious, TeckWrap Bond Gold reflects new-age nobility. Perfect for those who want a subtle yet refined metallic finish, this matte metallic vinyl wrap enhances your vehicle’s appearance with understated sophistication. Wrap your car to reveal your extraordinary side while protecting the original paint.

This wrap is part of TeckWrap’s matte metallic series, offering a flat metallic steel-like finish that is smooth, durable, and highly conformable. The material stretches easily to wrap every edge, curve, and recessed area, while the adhesive is safe, reliable, and easy to uninstall if needed.

Specifications

• Film Type: High-grade polymeric calendared vinyl with air-release channels
• Series: 190 Series
• Film Thickness: 121 µm
• Release Liner Thickness: 180 µm
• Adhesive: Henkel solvent-based acrylic, transparent, ultra-weather-resistant, viscosity 1000–3000 cps, thickness 12 µm dry
• Release Liner: Felix Schoeller Release Liner / 20-104-20-1.9 printed, double-side PE-coated Kraft (ISO 9001, ISO 14001, OHSAS 18001)
• Storage: +10°C to +20°C, 50% relative humidity, in original packaging, away from direct sunlight; shelf life: 3 years
• Durability/Warranty: Click here for TeckWrap Datasheet

Performance & Material Properties

• Release Force (N/25mm): Standard 0.04–0.12, Result: 0.1 (23℃, 54% RH)
• Initial Tack (g/25mm): Standard 800–1500, Result: 1254 (23℃, 54% RH)
• 180° Peel Strength (N/25mm): Standard ≥7.85, Result: 11.17 (23℃, 54% RH)
• Adhesion Strength: Standard ≥60, Result: 70 (No shifting)
• Post Heating: 100°C
• Aging: High-temperature 65℃ (7 days) and low-temperature -65℃ (10 days) without adhesive residue

Installation Guidelines

• Application Temperature: +17°C to +18°C
• Service Temperature: -45°C to +45°C
• Tools Needed: Soft squeegee with buffer
• Conformability: Flat and moderate curves, deep recesses with inlays
• Directional: Yes
• Overlap Width: 4–5 mm

Packaging

• Roll Width: 152 cm
• Roll Length: 18 m

Important Notes

• Screen images may not fully represent the color; always check the color swatch
• Use rolls from the same production LOT for consistent color
• Scratches during application or daily use are not covered under warranty
