Flame red (SMT15) Vinyl Wrap

Description

Express, not suppress. TeckWrap Flame Red is a bold statement of passion and individuality, designed to help your vehicle stand out with unstoppable energy and confidence.

Crafted from high-quality Renolit polymeric material, this vinyl wrap delivers excellent durability and conformability. It adapts smoothly to curves, edges, and recessed areas, making it ideal for full vehicle wraps or other complex surfaces.

Specifications

• Material: Renolit conformable polymeric vinyl
• Film Type: Pressure-sensitive high-grade polymeric vinyl with air-release channels
• Film Thickness: 0.12 mm
• Total Thickness (with liner): 0.28 mm
• Series: 190 Series
• Color: Flame Red (Corrected)

Adhesive & Liner

• Adhesive: Henkel solvent-based acrylic, transparent, ultra-weather-resistant (viscosity 1000–3000 cps, thickness 12 μm dry)
• Release Liner: Felix Schoeller, double-side PE coated Kraft, solventless silicone-coated with air-release (ISO 9001, ISO 14001, OHSAS 18001)

Performance

• Durability / Warranty: View Datasheet
• Post-Heating Temperature: 65°C
• Elongation at Break: MD 206.8% / CD 196.4% (ASTM D882-02)
• Tensile Strength: MD 29.5 / CD 24.8 N/mm² (ASTM D882-02)
• Dimensional Stability: 2% (ASTM D1204-02, 70°C)
• Surface Tension: 34 dynes/cm (ASTM D2578-04a)

Installation Guidelines

• Application Temperature: +17°C to +18°C
• Service Temperature: -45°C to +45°C
• Tools: Standard squeegee with soft (wet) buffer
• Surface Compatibility: Smooth and medium-curved surfaces
• Directional: Yes
• Overlap Width: 3–4 mm

Packaging

• Roll Width: 152 cm
• Length Options: 18 m or 23 m

Storage

• Storage Period: Up to 3 years
• Conditions: +10°C to +20°C, 50% humidity, original packaging, away from sunlight, clean and dry environment

Important Notes

• Colors and finishes may vary slightly—always check the physical swatch
• Use rolls from the same production lot for consistent color matching
• Film may scratch during installation or daily use; scratches are not covered under warranty
