Grau Pearl (RB30-HD) Vinyl Wrap

Description

TeckWrap Grau Pearl is slick and delicate. It generates true gloss of a natural pearl, a perfect symbol for the high class. Wrap it and ride with a premium experience.

Our Gloss Metallic vinyl wrap has a smooth, high-gloss finish and is crafted from the high-grade polymeric multilayered calendared vinyl film, complete with air release channels. Gloss Metallic wrap is durable and has good conformability; it’s stretchable enough to quickly wrap around every edge and recessed area of your vehicle. Gloss Metallic also uses a safe solvent polyacrylate adhesive, easy to install, and is gentle on car paint.

Specifications

Conformable polymeric material with stable color pigments, suitable for full car wrapping and other smooth or curved surfaces.

•  Film Thickness: 122 μm
•  Release Liner Thickness: 142 μm
•  Film Type: Premium-grade polymeric multilayered hybrid vinyl film with air-release channels
•  Roll Size: 1.52 m × 18 m (59.8″ × 708.6″, 4.98 ft × 59 ft, 1.66 yd × 19.6 yd)

Adhesive

•  Type: Henkel solvent-based acrylic adhesive
•  Properties: Transparent, ultra-weather-resistant
•  Viscosity: 1000–3000 cps
•  Thickness: 12 μm (dry)

Performance

•  Durability / Warranty: View Datasheet
•  Application Temperature: +17°C to +18°C
•  Service Temperature: -45°C to +45°C
•  Release Force: 0.17 N/25mm (Standard: 0.10–0.30)
•  Initial Tack: 840 g/25mm (Standard: 800–1500)
•  Peel Strength (180°): 8.7 N/25mm (Standard ≥ 6.8)
•  Adhesion Strength: 70 (Standard ≥ 60, no shifting)

Durability Tests

•  High-Temperature Aging: No adhesive residue (65°C, 7 days)
•  Low-Temperature Aging: No adhesive residue (-65°C, 10 days)

Installation Guidelines

•  Application Method: Standard method for calendered films (avoid overstretching)
•  Post-Heating Temperature: 100°C
•  Cure Time: 24 hours above 10°C
•  Tools: Squeegee, buffer, knife, masking tape, heat gun, magnets, gloves, IR thermometer, IR heater
•  Directional: Yes

Aftercare

•  Cleaning: Use pH-neutral products
•  Avoid: Wax and solvent-based cleaners

Important Notes

• Remove the protective cap before installation
• Colors and finishes may vary, always check the physical swatch
• Use rolls from the same production lot for consistent color matching
• Film may scratch during installation or daily use; scratches are not covered under warranty
