Golden Yellow (RB25-HD) Vinyl Wrap

Description

Bring the excitement trigger with you, and you shall never be bored. TeckWrap Golden Yellow is such a trigger that keeps you thrilled. Wrap to stay upbeat in your adventure.

Our Gloss Metallic vinyl wrap has a smooth, high-gloss finish and is crafted from the high-grade polymeric multilayered calendared vinyl film, complete with air release channels.  Gloss Metallic wrap is durable and has good conformability; it’s stretchable enough to quickly wrap around every edge and recessed area of your vehicle. Gloss Metallic also uses a safe solvent polyacrylate adhesive, easy to install, and is gentle on car paint.

Specifications

Conformable PVC material with stable color pigments, suitable for full car wrapping and other smooth or curved surfaces. Films with HD codes include plastic (PVC) liners.

•  Film Thickness: 0.15 mm
•  Total Thickness (with liner): 0.31 mm
•  Film Type: Premium-grade polymeric hybrid film with air-release channels
•  Series: 190 Series

Adhesive & Liner

•  Adhesive: Henkel solvent-based acrylic, transparent, ultra-weather-resistant (viscosity 1000–3000 cps, thickness 12 μm dry)
•  Release Liner: Felix Schoeller, double-side PE coated Kraft with solventless silicone coating and air-release (ISO 9001, ISO 14001, OHSAS 18001)

Performance

•  Durability / Warranty: View Datasheet
•  Dimensional Stability: Shrinkage less than 3% (matte), 5% (gloss)
•  Plastification: 27% – 35%
•  Breaking Strength: 22.7 N/10mm (ASTM D3759)
•  Peel Strength: 7.4 N/10mm (ASTM D3330)
•  Post-Heating Temperature: 110°C

UV Resistance

Test Standards: ASTM D4329-13 Cycle A & ISO 105-A02
Result: 5 (Pass)
Conditions: UVA-340, 8h UV at 60°C + 4h condensation at 50°C, duration 49h

Installation Guidelines

•  Application Temperature: +17°C to +18°C
•  Service Temperature: -45°C to +45°C
•  Tools: Standard squeegee with soft buffer
•  Surface Compatibility: Smooth and medium-curved surfaces
•  Directional: Yes
•  Overlap Width: 3–4 mm

Storage

•  Shelf Life: 2 years
•  Conditions: +10°C to +20°C, 50% humidity, original packaging, away from sunlight, clean and dry environment

Packaging

•  Roll Width: 152 cm
•  Length: 18 m
•  Weight: 14 kg

Important Notes

• Colors and finishes may vary, always check the physical swatch
• Use rolls from the same production lot for consistent color matching
• Film may scratch during installation or daily use; scratches are not covered under warranty
