Gold Pearl (CK525-HD) Vinyl Wrap

Description

Golden and decent, TeckWrap Gold Pearl represents noble and reputable. It’s a wrap of dignity, perfect for those looking to spice up a car with a splendid appearance. Order now to impress.

With a collection of stylish colors in both matte and gloss material, TeckWrap offers you this series of white chameleons vinyl wrap, which gives your vehicle a distinctive finish where it is partly shady with extraordinary luster. As a proud supplier, TeckWrap has many film selections with good conformability and durability. The material is stretchable enough to wrap every edge and the recessed area quickly. And the adhesive is safe without giving you any trouble when uninstalling. The better thing is that these vinyl wraps from TeckWrap are all high quality but reasonable and affordable.

Specifications

Conformable and highly flexible PVC material that can be molded to almost every part of a vehicle. Suitable for full car wrapping and other smooth or curved surfaces.

• Film Thickness: 0.15 mm
• Total Thickness (with liner): 0.31 mm
• Film Type: Premium-grade polymeric hybrid film with air-release channels

Adhesive & Liner

• Adhesive: Henkel solvent-based acrylic, transparent, ultra-weather-resistant (viscosity 1000–3000 cps, thickness 12 μm dry)
• Release Liner: Felix Schoeller, double-side PE coated Kraft with solventless silicone coating and air-release (ISO 9001, ISO 14001, OHSAS 18001)

Performance

• Durability / Warranty: View Datasheet
• Dimensional Stability: Shrinkage less than 2%
• Plastification: 23% – 32%
• Breaking Strength: 25.7 N/10mm (ASTM D3759)
• Peel Strength: 8.4 N/10mm (ASTM D3330)

UV Resistance

Test Standards: ASTM D4329-13 Cycle A & ISO 105-A02
Result: 4–5
Conditions: UVA-340, 8h UV at 60°C + 4h condensation at 50°C, duration 48h

Installation Guidelines

• Application Temperature: +17°C to +19°C
• Service Temperature: -45°C to +45°C
• Tools: Standard squeegee with soft buffer
• Surface Compatibility: Smooth and medium-curved surfaces
• Directional: Yes
• Overlap Width: 3–4 mm

Post-Installation

• Post-Heating Temperature: 100°C
• Cure Time: 48 hours

Storage

• Shelf Life: 2 years
• Conditions: +10°C to +20°C, 50% humidity, original packaging, away from sunlight, clean and dry environment

Packaging

• Roll Width: 152 cm
• Length: 18 m
• Weight: 14 kg

Important Notes

• Colors and finishes may vary—always check the physical swatch
• Use rolls from the same production lot for consistent color matching
• Film may scratch during installation or daily use; scratches are not covered under warranty
