Black Gold (HM09-HD) Vinyl Wrap

Description

A look that conveys stability, sophistication, and reliability. TeckWrap Black Gold is designed to enhance your vehicle’s presence with a high-class, premium finish. Ideal for full vehicle wraps or accent details, it highlights confidence and style while protecting your car’s paint.

TeckWrap provides a range of high-quality gloss HD films with excellent conformability and durability. The material is highly stretchable, allowing quick and smooth application over edges and recessed areas. The Henkel solvent-based acrylic adhesive is safe, easy to install, and removable without hassle. Products with “HD” in the SKU include a plastic release liner to enhance the high-gloss appearance.

Specifications

•  Film Type: Pressure-sensitive, premium-grade polymeric hybrid vinyl with air-release channels
•  Series: 190 Series
•  Available Colors: Black Cherry Ice, Gloss Green-Black, Burgundy Black, Sonoma Green, Gloss Beige Linen, Antique Green, Copper Bronze
•  Film Thickness: 0.13 mm
•  Film with Release Liner Thickness: 0.29 mm
•  Adhesive: Henkel solvent-based acrylic, transparent, ultra-weather-resistant, viscosity 1000–3000 cps, 12 µm dry thickness
•  Storage: Store at +10°C to +20°C, 50% humidity, away from direct sunlight; shelf life: 3 years
•  Durability/Warranty: Click here for TeckWrap Datasheet
•  Post Heating: 100°C
•  Surface Gloss (CD): 14.5% (ASTM D523-99, 60° angle)

Performance & Material Properties

•  Elongation / Break: MD: 206.8 / CD: 196.4 (ASTM D882-02)
•  Tensile Strength: MD: 29.5 / CD: 24.8 N/mm², Speed 200 mm/min (ASTM D882-02)
•  Dimensional Stability: 2% shrinkage at 70°C (ASTM D1204-02)
•  Surface Tension: 34 dynes/cm (ASTM D2578-04a, 24 hours after production)

Installation Guidelines

•  Application Temperature: +17°C to +18°C
•  Service Temperature: -45°C to +45°C
•  Tools Required: Standard squeegee with soft buffer
•  Conformability: Smooth and medium-curved surfaces
•  Directional: Yes
•  Overlap Width: 3–4 mm
•  Protective Cap: Peel off before installation

Packaging

•  Roll Width: 152 cm
•  Roll Length: 18 m
•  Weight: 13 kg

Important Notes

• Screen images may not fully reflect true color; always check the color swatch
• Use rolls from the same production LOT for consistent color
• Scratches during installation or daily use are not covered under warranty
