Azure Flame (GAL33-HD) Vinyl Wrap

Description

Unleash a wave of cool sophistication with TeckWrap Azure Flame. This premium aluminum vinyl wrap isn’t just a color change, it’s a statement. Its dynamic, high-gloss finish mimics the brilliance of a precious gemstone, making your vehicle stand out while protecting the underlying paint. With Azure Flame, vibrant color meets lasting durability and style.

TeckWrap’s collection of gloss HD colors ensures a solid, shiny finish without orange peel. The material is stretchable, allowing for quick wrapping around every edge and recessed area. The Henkel solvent polyacrylate adhesive is safe, easy to install, and removable without damaging car paint. All TeckWrap vinyl wraps are high-quality and affordable, delivering professional results every time.

Specifications

•  Film Type: Advanced polymeric multilayered vinyl with silver coating and air-release channels for smooth, bubble-free application
•  Film Thickness: 132 µm
•  Release Liner Thickness: 180 µm
•  High-Gloss Liner: Plastic liner for HD (“High Definition”) films
•  Roll Size: 1.52 m × 18 m (4.98 ft × 59 ft, 1.66 yd × 19.6 yd)
•  Adhesive: Henkel solvent polyacrylate, transparent, ultra-weather-resistant, viscosity 1000–3000 cps, 12 µm dry thickness
•  Note: SKUs with “HD” include the high-gloss plastic release liner

Durability & Performance

•  Release Force (N/25mm): 0.1 (Standard 0.10–0.30)
•  Initial Tack (g/25mm): 1055 (Standard 800–1500)
•  180° Peel Strength (N/25mm): 9.7 (Standard ≥7.85)
•  Adhesion Strength: 70 (Standard ≥60, no shifting)
•  Aging (65°C, 7 days): No adhesive residue
•  Aging (-65°C, 10 days): No adhesive residue
•  Storage / Shelf Life: Store at +17°C to +18°C, 50% humidity, away from sunlight; 2 years recommended

Installation Guidelines

•  Application Temperature: +17°C to +18°C
•  Service Temperature: -45°C to +45°C
•  Tools Required: Soft squeegee, buffer, knife, masking tape, heat gun, magnets, gloves, IRR thermometer, IRR heater
•  Application Method: Standard for calendered and hybrid films; clean surface thoroughly, avoid overstretching, post-heat flat surfaces 100°C, curves/overlaps 120°C
•  Cure Time: 24 hours above 15°C, recommended 48 hours at room temperature for maximum adhesion
•  Directional: Yes
•  Protective Cap: Peel off before installation

Aftercare

• Use PH-neutral cleaning products
• Avoid hot wax or strong solvents
• Handle carefully to avoid scratches

Important Notes

• Screen images may not fully represent the true color; always check the color swatch
• Use rolls from the same production LOT to ensure consistent color
• Scratches during application or daily use are not covered under warranty
